Dahua NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder
Dahua NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder
Dahua NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

Dahua

Dahua NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

(0)
SKU: NVR4104-P-EI
Barcode: 6923172585615

€233,90

All prices include VAT where applicable.

Eligible intra-EU B2B transactions with a valid VAT number may be subject to reverse charge under EU VAT rules.

In stock

Estimated delivery between 29 October and 31 October.

In stock and ready to ship

30 days satisfaction guarantee
Dahua NVR4104-P-EI 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder

€233,90

€233,90

Product Overview

The Dahua NVR4104-P-EI is a 4CH Smart 1U 4PoE 1HDD WizSense Network Video Recorder. It accepts 4 channels. Network throughput is specified as 80 Mbps incoming, 80 Mbps recording and 80 Mbps outgoing. Recording storage: 1 SATA port, up to 20 TB.The maximum HDD capacity varies with environment temperature. Recorder-side analytics support Face detection; face recognition; perimeter protection; and SMD.

Key Features

  • IP camera capacity: 4 channels
  • Incoming / recording / outgoing bandwidth: 80 Mbps incoming, 80 Mbps recording and 80 Mbps outgoing
  • Hard-drive interfaces: 1 SATA port, up to 20 TB.The maximum HDD capacity varies with environment temperature.
  • Local display connections: 1 HDMI, 1 VGA, 720 VGA
  • Recorder-side AI: Face detection; face recognition; perimeter protection; and SMD
  • Simultaneous playback: Up to 4 channels
  • Recording codecs: Smart H.265+; H.265; Smart H.264+; H.264; MJPEG

Technical Specifications

Intelligent analytics

SMD Plus by Recorder 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD by Camera All channels (16 targets/s)
Perimeter Performance AI by Recorder (Number of Channels) 2 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels) All channels (8 targets/s)
Face Detection Performance of AI by Recorder (Number of Channels) 1 channel (up to 12 face images/s each channel)
Face Recognition Performance of AI by Recorder (Number of Channels) 4-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s 1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
Face Database Capacity Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
AI by Recorder Face detection; face recognition; perimeter protection; and SMD
AI by Camera Face detection; face recognition; perimeter protection; SMD; ANPR; people counting; stereo analysis; heat map

Recording and video

Multi-channel Playback Up to 4 channels
Video Compression Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression G.711a; G.711u; PCM; G726
Access Channel 4 channels
Network Bandwidth 80 Mbps incoming, 80 Mbps recording and 80 Mbps outgoing
Decoding Capability AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 3-channel 6 MP@30 fps; 4-channel 5 MP@30 fps

Connectivity and power

Audio Input 1-channel RCA
Audio Output 1-channel RCA
Video Output 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI 1
VGA 1
USB 2 (2 rear USB 2.0 ports)
Network Port 1 (10/100 Mbps Ethernet port, RJ-45)
Power Supply 53 VDC, 1.226 A
Power Consumption < 10 W (without HDD) Total maximum output power of PoE is 45 W, the maximum output power of a single port is 25.5 W
Interoperability ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK

Storage and backup

Disk Interface 1 SATA port, up to 20 TB.The maximum HDD capacity varies with environment temperature.

Physical and environmental

Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Product Dimensions 204.6 mm × 206.4 mm × 45.6 mm (8.06" × 8.12" × 1.80") (W × D × H)
Net Weight 0.50 kg (1.10 lb)
Certifications FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Operating Humidity 10%–93% (RH), non-condensing

Model / SKU: NVR4104-P-EI. EAN: 6923172585615. Specifications apply to the stated configuration; conditional and optional functions are identified in the tables.
