Dahua NVR5432-EI WizSense 32CH Network Video Recorder 4HDD
Dahua NVR5432-EI WizSense 32CH Network Video Recorder 4HDD
Dahua NVR5432-EI WizSense 32CH Network Video Recorder 4HDD

Dahua

Dahua NVR5432-EI WizSense 32CH Network Video Recorder 4HDD

(0)
SKU: NVR5432-EI
Barcode: 6923172589842

€600,31

All prices include VAT where applicable.

Eligible intra-EU B2B transactions with a valid VAT number may be subject to reverse charge under EU VAT rules.

In stock

Estimated delivery between 30 October and 01 November.

In stock and ready to ship

30 days satisfaction guarantee
Dahua NVR5432-EI WizSense 32CH Network Video Recorder 4HDD

€600,31

€600,31

Product Overview

The Dahua NVR5432-EI is a WizSense 32CH Network Video Recorder 4HDD. It accepts 32 channels. Network throughput is specified as AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing. Recording storage: 4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature. Recorder-side analytics support Face detection; face recognition; perimeter protection; SMD Plus.

Key Features

  • IP camera capacity: 32 channels
  • Incoming / recording / outgoing bandwidth: AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
  • Hard-drive interfaces: 4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
  • Local display connections: 2 VGA, 2 HDMI, 720 HDMI
  • Recorder-side AI: Face detection; face recognition; perimeter protection; SMD Plus
  • Simultaneous playback: Up to 16 channels
  • Recording codecs: Smart H.265+; H.265; Smart H.264+; H.264; MJPEG

Technical Specifications

Intelligent analytics

SMD Plus by Recorder 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
SMD by Camera All channels (32 targets/s) Video Metadata
Perimeter Performance AI by Recorder (Number of Channels) 4 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels) All channels (16 targets/s)
Face Detection Performance of AI by Recorder (Number of Channels) 2 channels (up to 12 face images/s each channel)
Face Recognition Performance of AI by Recorder (Number of Channels) 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s
Face Database Capacity Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
AcuPick Performance of AI by Camera (Number of Channels) Max. 32-channel, 1 combined event per channel/s
AI by Recorder Face detection; face recognition; perimeter protection; SMD Plus
AI by Camera Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection

Recording and video

Multi-channel Playback Up to 16 channels
Video Compression Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression G.711a; G.711u; PCM; G726
Access Channel 32 channels
Network Bandwidth AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Decoding Capability AI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 10-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps AI enabled: 1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 6 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps

Connectivity and power

Audio Input 1-channel RCA
Audio Output 2-channel RCA
Alarm Input 16 channels
Alarm Output 6 channels (1-channel 12 V 1 A output）
Video Output 2 VGA, 2 HDMI VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source output for VGA2 and HDMI2
HDMI 2
VGA 2
USB 3 (1 front USB 2.0 port, 2 rear USB 3.0 ports)
Network Port 2 (10/100/1000 Mbps Ethernet port, RJ-45)
Power Supply 100–240 VAC, 50-60 Hz
Power Consumption Total output of NVR is ≤ 13 W (without HDD)
Interoperability ONVIF 25.06 (Profile T; Profile S; Profile G; Profile M); CGI; SDK

Storage and backup

Disk Interface 4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
Disk Group YES

Physical and environmental

Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Product Dimensions 440.0 mm × 415.1 mm × 70.0 mm (17.32" × 16.34" × 2.76") (W × D × H)
Net Weight 4.74 kg (10.45 lb)
Certifications FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014 4 HDDs eSATA Storage
Operating Humidity 10%–93% (RH), non-condensing

Model / SKU: NVR5432-EI. EAN: 6923172589842. Specifications apply to the stated configuration; conditional and optional functions are identified in the tables.
