Dahua
Dahua HDW2449TM-S-IL-0280B-B 4MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera
SKU: HDW2449TM-S-IL-0280B-B
€116,50
All prices include VAT where applicable.
Eligible intra-EU B2B transactions with a valid VAT number may be subject to reverse charge under EU VAT rules.
In stock
Estimated delivery between 30 October and 01 November.
Dahua HDW2449TM-S-IL-0280B-B 4MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera
€116,50
€116,50
Product Overview
The black Dahua HDW2449TM-S-IL-0280B-B combines 4MP Smart Dual Light imaging with a 2.8 mm fixed lens and integrated microphone in an eyeball design. Its 1/2.9" CMOS sensor captures 2688 (H) × 1520 (V) with 120 dB wide dynamic range. Night illumination is specified at up to 30 m (IR); up to 30 m (Warm light). Video analytics include tripwire, intrusion with human and vehicle classification. The camera includes a built-in microphone, microSD recording up to 256 GB.
Key Features
- 2688 (H) × 1520 (V) maximum image resolution with 1/2.9" CMOS sensor
- 2.8 mm fixed-focal lens; H: 95°; V: 52°; D: 114° field of view
- Night coverage: up to 30 m (IR); up to 30 m (Warm light)
- Tripwire and intrusion detection with human/vehicle classification
- A built-in microphone, microSD recording up to 256 GB
- Power options: 12 VDC/PoE (802.3af); IP67 enclosure protection
Technical Specifications
Imaging and lens
| Min. Illumination | 0.006 lux@F1.6 (Color, 30 IRE) 0.0006 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) |
|---|---|
| Image Sensor | 1/2.9" CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| Lens Type | Fixed-focal |
| Focal Length | 2.8 mm |
| Max. Aperture | F1.6 |
| Field of View | H: 95°; V: 52°; D: 114° |
Illumination and video
| Illumination Distance | up to 30 m (98.43 ft) (IR); up to 30 m (98.43 ft) (Warm light) |
|---|---|
| Video Frame Rate | Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Video Compression | H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| WDR | 120 dB |
| Stream Capability | 2 streams |
| Noise Reduction | 3D NR |
Intelligent analytics
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
|---|
Connectivity and power
| Built-in MIC | Yes |
|---|---|
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB) |
| Network Port | RJ-45 (10/100 Base-T) |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 2.1 W (12 VDC); 2.5 W (PoE) Max. (H.265 + intelligence on + WDR + warm light): 4.4 W (12 VDC); 5.2 W (PoE) |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI |
Physical and environmental
| Colour | Black |
|---|---|
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Protection | IP67 |
| Casing Material | Inner core: Metal; Cover: Metal; Decoration ring: Plastic |
| Product Dimensions | 99.1 mm × Φ121.9 mm (3.90" × Φ4.80") |
| Net Weight | 0.46 kg (1.01 lb) |
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Operating Humidity | ≤95% |
Model / SKU: HDW2449TM-S-IL-0280B-B. EAN: 6923172578624. Specifications apply to the stated configuration; conditional and optional functions are identified in the tables.
