Dahua NVR4208-8P-4KS3 8CH 1U 8PoE 2HDDs Lite Network Video Recorder
Dahua NVR4208-8P-4KS3 8CH 1U 8PoE 2HDDs Lite Network Video Recorder
Dahua NVR4208-8P-4KS3 8CH 1U 8PoE 2HDDs Lite Network Video Recorder

Dahua

Dahua NVR4208-8P-4KS3 8CH 1U 8PoE 2HDDs Lite Network Video Recorder

(0)
SKU: NVR4208-8P-4KS3
Barcode: 6923172569363

€289,93

All prices include VAT where applicable.

Eligible intra-EU B2B transactions with a valid VAT number may be subject to reverse charge under EU VAT rules.

Low in stock

Estimated delivery between 30 October and 01 November.

In stock and ready to ship

30 days satisfaction guarantee
Dahua NVR4208-8P-4KS3 8CH 1U 8PoE 2HDDs Lite Network Video Recorder

€289,93

€289,93

Product Overview

The Dahua NVR4208-8P-4KS3 is an 8CH 1U 8PoE 2HDDs Lite Network Video Recorder. It accepts 8 channels. Network throughput is specified as AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing. Recording storage: 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. Recorder-side analytics support SMD.

Key Features

  • IP camera capacity: 8 channels
  • Incoming / recording / outgoing bandwidth: AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
  • Hard-drive interfaces: 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
  • Local display connections: 1 HDMI, 1 VGA, 720 VGA
  • Recorder-side AI: SMD
  • Simultaneous playback: Up to 8 channels
  • Recording codecs: Smart H.265+; H.265; Smart H.264+; H.264

Technical Specifications

Intelligent analytics

SMD Plus by Recorder 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD by Camera All channels (12 targets/s)
Perimeter Performance of AI by Camera (Number of Channels) 6 channels
AI by Recorder SMD
AI by Camera Face detection; face recognition; perimeter protection; SMD; people counting; stereo analysis; heat map

Recording and video

Multi-channel Playback Up to 8 channels
Video Compression Smart H.265+; H.265; Smart H.264+; H.264
Audio Compression G.711a; G.711u; PCM; G726
Access Channel 8 channels
Network Bandwidth AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Decoding Capability AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps

Connectivity and power

Audio Input 1-channel RCA
Audio Output 1-channel RCA
Alarm Input 4 channels
Alarm Output 2 channels (1-channel 12 V 1 A output）
Video Output 1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI 1
VGA 1
USB 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
Network Port 1 (10/100/1000 Mbps Ethernet port, RJ-45)
Power Supply 100–240 VAC, 50/60 Hz
Power Consumption Total output of NVR is <10 W(without HDD) Total output power of PoE is 130 W, the maximum output power of a single port is 25.5 W
Interoperability ONVIF 24.12 (Profile T; Profile S; Profile G); CGI; SDK

Storage and backup

Disk Interface 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
Disk Group Yes

Physical and environmental

Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Product Dimensions 375.0 mm × 327.9 mm × 53.0 mm (14.76" × 12.91" × 2.09") (W × D × H)
Net Weight 2.47 kg (5.45 lb)
Certifications CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Operating Humidity 10%–93% (RH), non-condensing

Model / SKU: NVR4208-8P-4KS3. EAN: 6923172569363. Specifications apply to the stated configuration; conditional and optional functions are identified in the tables.
